Technical Parameters:
NO. | DL361-E-1 | Parameters |
1 | Max. Weight for Core Box | 6kg |
2 | Max. Size of Core Box (L*W*H) | 550*380*300mm |
3 | Size of Heating Plate (L*W*H) | 350*200*50mm |
4 | Heating Power | 9.6kw |
5 | Ejector Vertical Stroke | ≤30mm |
6 | Die Opening Stroke | ≤300mm |
7 | Core-pulling Stroke | 150mm |
8 | Size of Conveyor Belt (L*W*H) | 1850*400*100mm |
9 | Machine Power | 10kw |
10 | Ascending Angle of Conveyor Belt | 2-4° |
11 | Conveying Speed | 72mm/s |
12 | Net Weight | 1350kg |
13 | External Dimensions (L*W*H) | 3250*1350*2380mm |
