TW-800 series
Ancon
For customers to realize the processing production lines required for parts processing, drilling, reaming, boring, slotting, tapping, etc., to provide efficient, intelligent, and low-input overall processing solutions. We can develop and customize various metal automatic processing special machines according to customer needs.
Technical Parameter:
| TW series horizontal machining centre (Dual table) | ||||||
| TW series | Unit | TW-500 | TW-630 | TW-800 | TW-1016 | TW-1225 |
| Stroke length of X axis | mm | 700 | 1000 | 1300 | 1600 | 2200 |
| Stroke length of Y axis | mm | 550 | 750 | 800 | 1100 | 1100 |
| Stroke length of Z axis | mm | 600 | 800 | 800 | 1250 | 1250 |
| Distance from spindle nose to workbench | mm | 120-720 | 130-930 | 230-1030 | 230-1480 | 230-1480 |
| Distance from spindle center to worktable | mm | 100-700 | 120-920 | 150-950 | 150-1250 | 150-1250 |
| Spindle taper | BT50 | BT50 | BT50 | BT50 | BT50 | |
| Spindle rotating speed | rpm | 6000 | 6000 | 6000 | 6000 | 6000 |
| Machining feed | m/min | 1-6000 | 1-6000 | 1-8000 | 1-8000 | 1-8000 |
| Rapid feed(X/Y/Z) | m/min | 24/24/24 | 24/24/24 | 24/24/24 | 24/24/24 | 24/24/24 |
| X/Y/Z Three axis motor | kw | 3/3/3 | 3/3/3 | 7/7/7 | 7/7/7 | 7/7/7 |
| Positioning precision | mm | 0.005 | 0.008 | 0.012 | 0.012 | 0.012 |
| Repeated precision | mm | 0.003 | 0.005 | 0.008 | 0.008 | 0.008 |
| Spindle motor | kw | 15 | 15 | 22 | 22 | 22 |
| Spindle transmission way | Belt(ZF Gear case) | |||||
| Bearing diameter | mm | 100 | 100 | 100 | 100 | 100 |
| Worktable size | mm | 500*500*2 | 630*630*2 | 800*800*2 | 1000*1000*2 | 1200*1000*2 |
| Working table motor specifications | kw | 3*2 | 3*2 | 3*2 | 3*2 | 3*2 |
| T-Slot | mm | 100*18*4 | 100*18*5 | 125*22*6 | 150*22*6 | 150*22*7 |
| Max speeding of worktable | rpm | 11.1 | 11.1 | 11.1 | 11.1 | 11.1 |
| Dividing of worktable | 1°*360 | 1°*360 | 1°*360 | 1°*360 | 1°*360 | |
| Load of worktable | kg | 500 | 800 | 2000 | 3000 | 3000 |
| Locking force | kg/cm² | 4000 | 4000 | 5000 | 5000 | 5000 |
| Cutting precision | sec | 5 | 5 | 5 | 5 | 5 |
| Types of tool changers | Chained | Chained | Chained | Chained | Chained | |
| Tool magazine capacity | T | 40 | 40 | 40 | 40 | 40 |
| Maximum weight tool | kg | 15 | 15 | 15 | 15 | 15 |
| Maximum length tool | mm | 300 | 300 | 300 | 300 | 300 |
| Maximum diameter tool | mm | 125 | 125 | 125 | 125 | 125 |
| Tools exchange time | sec | Tool to tool | Tool to tool | Tool to tool | Tool to tool | Tool to tool |
| Air compressor supply | kg/cm² | 6 | 6 | 8 | 8 | 8 |
| Power supply | kva | 40 | 40 | 55 | 55 | 55 |
| Machine net weight | kg | 13000 | 19000 | 24000 | 26000 | 29000 |
Technical reference：
Using double spiral chip discharge + chain side discharge, the chips can be automatically removed in time and effectively, to avoid the thermal impact of chips on the machine tool, and to ensure the accuracy of machine processing. The fully enclosed sheet metal effectively guarantees that the chips and coolant are confined inside the processing area.
Our Service:
We have strict management system,complete quality guarantee system and fine pre-sale and after-sale service system.
1.Pre-sale Service System
Please do not hesitate to contact with us If you are interested in machine. We can design the machine you requirements.
2.After-sale Service System
24/7 on line,including mobile/wechat/whatsapp etc. Our technician is available to visit and go to your place,and they will help your side for installation,maintenance,and training.
3.Payment
30% Deposit by TT,and The rest 70% by photos or you can check the quality on our factory before they shipment.
